Elegance Wave 15mm Chrome Corner TRV

Special Price £11.81 (Inc.Vat)



Special Price £ 36.79   SAVE: 68%

Availability: In Stock




The Elegance Wave corner TRV (thermostatic radiator valve) is a modern bi-directional fully chrome headed valve that's ideal for awkward installations in tight corners. To set the required room temperature, rotate the thermostat head clockwise or anti-clockwise between the 1 and 5, aligning the number with the vertical indicator as shown.
Specifications:
Normal flow rate: 150kg/h
Max. flow rate: 470kg/h
Max. working pressure: 10 bar
Max. pressure differential: 1 bar
Max. water temperature: 100C
Max. ambient temperature: 50C
Temperature adjustment range: 7C-28C
Response time: 24 mins
Water temperature effect: 1.40K
Valve Position - Corner
Connections - 15mm x 1/2"
Valve Type - Thermostatic
Valve Style - Premium
Valve Colour - Chrome
Manufacturers Warranty - 1 Year (Subject to Manufacturers T and C)

Product Code:
EV-EC15C
Weight:
0.40kg
Manufacturer
BiWorld
Model:
15mm x 1/2"
Width:
76.00 mm
Height:
116.00 mm
Depth
50.00
MPN
EV-EC15C
